Spesifikasi Produk
General
Cabinet Type: Chest
Ambient Temperature: 5 °C ~ 43 °C
Cooling Type: Direct Cooling
Refrigerant: HC
Sound Level: < 40 dB(A)
Temperature & Control
Temperature Range: 2 ~ 8 °C
Freezer Protection Level: A
Controller: Microprocessor
Display: Solar LED Temperature Display
Electrical
Power Supply: 220–240 V / 50 Hz
Power: 110 W
Electrical Current: 0.9 A
Power Consumption (Stable Running): 0.57 kWh / 24 h
Power Consumption (Cool Down Test): 0.63 kWh / 24 h
Performance
Holdover Time at 43 °C: 59 hours 58 minutes
Holdover Time at 32 °C: 98 hours 26 minutes
Capacity
Vaccine Storage Capacity: 61 L / 2.2 cu.ft
Gross Volume: 80 L / 2.8 cu.ft
Weight
Net Weight: 85 kg / 187.6 lbs
Gross Weight: 110 kg / 242.7 lbs
Dimensions
Interior Dimensions (W × D × H)
500 × 366 × 560 mm
19.7 × 14.4 × 22 in
Exterior Dimensions (W × D × H)
788 × 717 × 872 mm
31 × 28.2 × 34.3 in
Packing Dimensions (W × D × H)
850 × 770 × 1080 mm
33.5 × 30 × 42.5 in
Container Load
20’ / 40’ / 40’H: 36 / 78 / 78 units
Alarm & Safety
High / Low Temperature
Sensor Error
Structure & Accessories
Foot / Castor: Foot
Baskets: 1
Data Logger: Yes
Automatic Voltage Stabilizer: Optional
Remote Temperature Monitoring Device (RTMD): Optional
Certification
CE
WHO / PQS
Deskripsi Produk
Refrigeration System
• Optimized refrigeration system design
• Cabinet structure designed specifically to maintain
2°C to 8°C for more than 55 hours at 43°C ambient
• HC high-density foam insulation
• Complies with WHO/UNICEF standards Grade
A freeze protection to ensure vaccine never freezes
in the storage compartment
• Wide ambient temperature range, from 5°C -43°C
Ergonomic Design
• Door lock for storage safety
• Indicator light to show whether compressors on or off status
• Independent temperature data logger to monitor,record and manage temperature records
• Operates within wide voltage range,172~264 volts
Temperature Control
• Digital solar powered temperature display • Internal temperature range is 2°C to 8°C
