AZtecLive Spectrum (LiveStep) Live and continually refreshed: - Live Spectrum with automatically labelled peaks and MiniQuant showing quantitative results - Live Spectrum Viewer’ window Image Acquisition - (Resolution up to 2048) Capability to acquire SE and BSE images sequentially into the same ‘Site Of Interest’ Spectrum Acquisition - collect data from point, rectangular, elliptical and irregular acquisition areas - Spectra can also be reconstructed from existing Smartmap and LineScan datacubes Tru-Q - is a unique combination of new and existing technologies that make the promise of automatic, real-time element identification and composition determination a reality. AutoID and standardless analysis can be achieved X-ray Mapping - (Resolution up to 1024) Collects a spectral map data cube from rectangular, elliptical or irregular areas. LineScanning - Collects a spectral line datacube HARDWARE Xplore High throughput Silicon Drift EDS Detector 30 mm2 Sensor sizes SATW Light Element Window, for detection of elements from boron Resolution guaranteed on customers microscope: MnKα (129eV @100,000cps) X1 Pulse Processor and Imaging Electronics X1 is the latest generation pulse processor with fully integrated microscope digital control and image capture. X1 uses fully digital pulse processing for accurate handling of very high count rates. Ethernet high speed communications connect with the analyzer PC Digital pulse processing and control for 1 EDS detector 2 imaging inputs Microscope X,Y beam control Power on, standby, reset button Status indicator Internal Temperature sensors Built in diagnostic voltage and current measurements
